RS-122-E01
Rack Mount Thin Client
Description：
- Intel J1900 / E3845 CPU
- Up to 8GB DDR3 SO-DIMM Memory
- Dual Gigabit LAN
- 5 x USB
- ThinManager Ready, PXE
- Up to 2x Thin Clients per 1U Rack
-
Specification RS-122-E01-003 System CPU Intel Celeron J1900 @ 1.99GHz / Atom E3845 @ 1.91GHz CPU Chipset Bay Trail Memory Up to 8GB DDR3 SO-DIMM Video Controller Intel Gen7 Intel Graphics DX 11, OGL3.2 Video Interface VGA + HDMI Storage Option N/A CFast N/A Keyboard/Mouse USB Audio Mic In, Line Out Watchdog Timer N/A Remote Boot ThinManager Ready, PXE Expansion Slot N/A I/O Communication USB Port 5 x USB Serial Port 2x RS-232 IEEE 1394 N/A LAN 2 x Gigabit Parallel N/A GPIO N/A Smart Battery External Smart Battery N/A OS Support OS Support N/A Power / Thermal Specs. Power Requirement (Max) Power Consumption (Average) Recommended Power Supply Heat Dissipation Physical Information Mounting Rack Mount New Weight Dimension (W x H x D) Standard 19" / 1U Rack Mount Environmental Operating Temperature 0~35°C (32~95°F) Storage Temperature -20~60°C (-4~140°F) Relative Humidity 0~95% IP/NEMA Rating N/A Certification -
Ordering Information RS-122-E01-003-1 RS-122-E01-003-2 CPU J1900 / E3845 CPU J1900 / E3845 CPU Memory 4GB DDR3 4GB DDR3 Storage N/A N/A Remote Boot ThinManager Ready ThinManager Ready Power Supply 110/220VAC Input 110/220VAC Input Operating System N/A N/A -
Document Datasheet 2D Line Drawing User Manual N/A PDF N/A Brochure Brochure Brochure Datasheet Flyer Pharma Manufacturing Industrial Thin Client Industrial KVM Extender Powered by PoE Series Industrial KVM Extender
Download Download Download Download Download Datasheet Datasheet Datasheet Fanless Compact Computers Expandable Fanless Computers Rack Mount Computers
Download Download Download
-
Part #: Please contact Arista sales representative for more information Telephone: +1-510-226-1800 Email: sales@goarista.com
-
Specifications
Specification RS-122-E01-003 System CPU Intel Celeron J1900 @ 1.99GHz / Atom E3845 @ 1.91GHz CPU Chipset Bay Trail Memory Up to 8GB DDR3 SO-DIMM Video Controller Intel Gen7 Intel Graphics DX 11, OGL3.2 Video Interface VGA + HDMI Storage Option N/A CFast N/A Keyboard/Mouse USB Audio Mic In, Line Out Watchdog Timer N/A Remote Boot ThinManager Ready, PXE Expansion Slot N/A I/O Communication USB Port 5 x USB Serial Port 2x RS-232 IEEE 1394 N/A LAN 2 x Gigabit Parallel N/A GPIO N/A Smart Battery External Smart Battery N/A OS Support OS Support N/A Power / Thermal Specs. Power Requirement (Max) Power Consumption (Average) Recommended Power Supply Heat Dissipation Physical Information Mounting Rack Mount New Weight Dimension (W x H x D) Standard 19" / 1U Rack Mount Environmental Operating Temperature 0~35°C (32~95°F) Storage Temperature -20~60°C (-4~140°F) Relative Humidity 0~95% IP/NEMA Rating N/A Certification -
Ordering Information
Ordering Information RS-122-E01-003-1 RS-122-E01-003-2 CPU J1900 / E3845 CPU J1900 / E3845 CPU Memory 4GB DDR3 4GB DDR3 Storage N/A N/A Remote Boot ThinManager Ready ThinManager Ready Power Supply 110/220VAC Input 110/220VAC Input Operating System N/A N/A -
